The HUAWEI B636-336 is a high-performance 4G LTE wireless gateway tailored for households and small office environments.

Supporting 3GPP Release 13, it offers seamless internet access with peak download speeds of up to 400 Mbps and upload speeds reaching 200 Mbps.

It supports multiple LTE bands for global compatibility and is also backward compatible with UMTS networks.

Equipped with advanced Wi-Fi 6 technology, this router provides robust dual-band wireless connectivity ideal for multiple-device environments, supporting up to 128 simultaneous users.

HUAWEI B636-336 Specifications

  • Network & Technology:

    • LTE Categories: DL CAT 13, UL CAT 18

    • Supported LTE Bands: B1, B3, B5, B7, B8, B20, B28, B32, B38, B40, B41, B42, B43

    • UMTS Bands: B1, B5, B8

    • Max Download Speed: 400 Mbps

    • Max Upload Speed: 200 Mbps

  • Wi-Fi:

    • Standard: 802.11 b/g/n/a/ac/ax (Wi-Fi 6)

    • Frequency Bands: Dual-band 2.4 GHz (up to 574 Mbps) and 5 GHz (up to 2400 Mbps)

    • MIMO: 2×2 on both bands

    • Max Connected Devices: 128

  • Ports and Slots:

    • 1x RJ11 port for voice calls (via SIM or VoIP)

    • 1x RJ45 WAN/LAN Gigabit Ethernet port

    • 3x RJ45 LAN Gigabit Ethernet ports

    • 1x Nano-SIM card slot

    • 2x SMA connectors for external LTE antennas

  • Physical Attributes:

    • Dimensions: 198 mm (W) x 125 mm (H) x 27.9 mm (D)

    • Weight: About 305 grams

    • Power: AC 100-240V input, 12V/1A output

    • Operating Temperature: 0°C to 40°C

    • Storage Temperature: -20°C to 70°C

  • Additional Technical Details:

    • Support for Multi APN function (data, voice, TR-069)

    • Supports VPN client services (L2TP, PPTP)

    • Huawei Firmware Over the Air (HOTA) update capability

    • Supports TR-069 and TR-143 for remote maintenance (optional)

    • Security: Firewall, URL filtering, MAC address filtering, WPA2-PSK, WPA3-SAE, and others

    • Supports WPS and MU-MIMO for better Wi-Fi management

HUAWEI B636-336 Key Features

  • 4G LTE CAT 13: High-speed mobile broadband with aggregated LTE bands for fast and reliable internet access.

  • Dual-band Wi-Fi 6 (802.11ax): Provides enhanced wireless performance and capacity with improved speed and connection stability.

  • Multi-User Support: Connects up to 128 devices simultaneously, ideal for homes and small offices.

  • Versatile Connectivity: Multiple Gigabit Ethernet ports including a WAN/LAN port and an RJ11 port for voice services.

  • External Antenna Support: Includes two SMA ports allowing connection of external LTE antennas to boost signal strength.

  • Security and Management: Robust firewall protection, VPN client support, and easy management via Huawei AI Life App and web UI.

  • Firmware Over The Air (HOTA): Enables automatic or manual updates to keep the device secure and optimized.

  • Compact and Lightweight: Sleek design with a light body for easy placement in any environment.

HUAWEI B636-336 Firmware and Manual

Huawei provides firmware updates for the B636-336 that can be performed via the Huawei AI Life App or through a web-based interface.

Firmware updates enhance security, fix bugs, and add new features. Huawei supports remote updates via HOTA (Huawei Over The Air).

User manuals and quick-start guides are available online to assist with the router setup, configuration, and troubleshooting.

These guides provide step-by-step instructions to insert a SIM card, connect the power supply, access the management interface, and customize the router settings.

HUAWEI B636-336 Price

The HUAWEI B636-336 typically retails around a mid-range price for LTE routers, with prices varying depending on region and retailer.

Online retailers list it approximately within a competitive range for a Wi-Fi 6 LTE router (prices can fluctuate with promotions). It is available through multiple distributors with warranty and after-sales support.

Conclusion

The router is well-reviewed for its combination of fast LTE CAT 13 speeds and Wi-Fi 6 connectivity.

Users appreciate the strong multi-device support and flexible network options, including voice calls through the RJ11 port.

The device is praised for solid build quality, stable signal performance, and ease of management with the Huawei AI Life app.

Some feedback highlights the router’s suitability for both home and small office settings where reliable mobile broadband is needed.

The external antenna ports are a plus for users in weaker signal areas.

The overall consensus is that the Huawei B636-336 is a versatile and reliable LTE router with modern features at a reasonable price point.

This summary provides a thorough view of the HUAWEI B636-336 router for prospective buyers, tech enthusiasts, and small business users seeking a powerful 4G LTE router with Wi-Fi 6 capabilities.
