The Huawei B535 232 is a versatile and reliable 4G LTE home broadband router designed to provide fast wireless internet connectivity for households and small offices.

It supports dual-band Wi-Fi, high-speed LTE connectivity, and multiple device connections, making it suitable for a range of internet usage scenarios.

Overview

The Huawei B535 232 LTE CPE (Customer Premises Equipment) router offers an easy setup for home or office internet access via 4G LTE networks.

It acts as a wireless gateway, supporting up to 64 simultaneous device connections, and includes Ethernet ports for wired connectivity.

The device features dual-band Wi-Fi (2.4 GHz and 5 GHz) and dual external antenna ports to enhance network performance.

Huawei b535 232 Specifications

LTE Category: Cat 7

Download Speed: Up to 300 Mbps

Upload Speed: Up to 100 Mbps

Wi-Fi Standards: IEEE 802.11a/b/g/n/ac (dual-band)

Wi-Fi Speeds: 2.4 GHz up to 300 Mbps, 5 GHz up to 867 Mbps

Maximum Connected Devices: 64

Ethernet Ports: 4 Gigabit LAN ports, one of which can be used as WAN

SIM Card Slot: Micro-SIM

External Antenna Ports: 2 x SMA connectors for LTE antennas

Dimensions: 219 mm (W) x 138 mm (H) x 25.6 mm (D) (without socket)

Weight: Approximately 330 g

Power: AC input 100-240V, DC output 12V/1A

Operating Temperature: 0°C to 40°C

Key Features

Dual-band Wi-Fi 5 (802.11ac) with 2×2 MIMO technology

Supports multi-APN and multiple user authentication modes

NAT, firewall, URL filtering, and port forwarding for enhanced security

Modem supports LTE bands B1, B3, B7, B8, B20, B28, B32, B38, and UMTS bands B1, B8

Easy network diagnostics and management via web interface

Guest Wi-Fi network supported

WPS (Wi-Fi Protected Setup) for quick connection

Supports VPN client functionality (L2TP, PPTP)

Performance

The Huawei B535 232 delivers reliable 4G LTE Cat 7 speeds up to 300 Mbps download and 100 Mbps upload, suitable for streaming, gaming, and general internet browsing.

The dual-band Wi-Fi ensures good wireless coverage and speed, although obstacles such as walls can reduce range.

The b535 232 huawei router supports up to 64 devices simultaneously, making it ideal for households or small office environments.

The Gigabit Ethernet ports provide fast wired connections for devices requiring stable throughput.

Step By Step Setup

1. Position the router in an elevated, open space preferably near a window for best signal.

2. Insert a compatible Micro-SIM card into the SIM slot.

3. Connect the power adapter and switch on the device.

4. Connect devices via Wi-Fi or Ethernet; default Wi-Fi credentials are printed on the router.

5. Access the router’s admin panel via a browser (usually at 192.168.8.1) to configure advanced settings such as Wi-Fi SSID/password, network modes, and parental controls.

 Huawei B535 232 Manual

The full user manual is available online for detailed instructions on device setup, configuration, troubleshooting, and advanced features.

It covers topics such as network status indicators, SIM card management, security settings, and system diagnostics.

Firmware Update

Firmware updates can be done through the router’s admin panel by navigating to the system settings.

Many versions support automatic update features to keep the router secure and enhance functionality.

Users can also manually download updates from Huawei’s official support page.

External Antenna Support

The Huawei B535 232 includes two SMA connectors for external LTE antennas, allowing users to improve signal strength and data speeds, especially in areas with weak coverage.

To install, power off the device, connect the compatible external antennas securely, and place the router in a location that maximizes signal reception indoors.

Only carrier-approved antennas should be used to ensure device safety and performance.

Conclusion

The Huawei B535 232 is a solid choice for users seeking a high-speed, reliable 4G LTE router with dual-band Wi-Fi and strong multi-device support.

Its straightforward setup, solid performance, and external antenna support make it adaptable for various home and small office internet needs.

While not a 5G router, its speed and features are highly competent for areas with strong 4G coverage, ensuring a robust internet experience.

huawei 4g router b535 232 balances performance, usability, and expandability, making it a commendable option in the LTE router market.
