SoyeaLink B535-333 LTE Router Overview

The SoyeaLink B535-333 LTE Router is a versatile 4G LTE Cat 7 wireless gateway designed for home or small office environments.

It supports high-speed internet access over LTE networks and offers dual-band Wi-Fi functionality for robust wireless performance.

SoyeaLink B535-333 LTE Router is unlocked and compatible with any SIM card worldwide, making it a flexible connectivity solution.

Here is a comprehensive article on the SoyeaLink B535-333 LTE Router including its details:

Specifications

  • Network Category: LTE Category 7

  • Max Download Speed: Up to 400 Mbps

  • Max Upload Speed: Up to 150 Mbps

  • LTE Bands Supported: B1, B3, B7, B8, B20, B28, B32, B38 (varies by region)

  • Wi-Fi: Dual Band Wi-Fi AC1200 (2.4 GHz & 5 GHz) with 802.11a/b/g/n/ac

  • Wi-Fi Speed: Up to 1167 Mbps total

  • Ethernet Ports: 4 x Gigabit Ethernet Ports (1 LAN/WAN + 3 LAN)

  • Telephone Port: 1 x RJ11 Port (TEL) for VoIP/telephone services

  • SIM Card Slot: Micro SIM (3FF)

  • Antenna: 2 external SMA antenna ports + internal antennas

  • Max Wireless Devices: Supports up to 64 simultaneous connections

  • VPN Support: L2TP, PPTP VPN client support

  • Security: WPA/WPA2-PSK, WPA3-SAE, WEP encryption, MAC address filtering

  • Additional Features: WPS button, recessed reset button, multi-APN support, TR-069 management

Key Features

  • High-Speed LTE Connectivity: Cat 7 support delivers fast and reliable internet with up to 400 Mbps download speed.

  • Dual-Band Wi-Fi: Provides both 2.4 GHz and 5 GHz Wi-Fi bands to reduce interference and optimize wireless performance.

  • Multiple Ethernet Ports: Wired connections available via multiple Gigabit ports including one that can function as WAN or LAN.

  • Telephone Support: RJ11 port for connecting a landline phone or VoIP service.

  • Easy Setup & Management: User-friendly web interface and Huawei AI Life App for configuration.

  • Robust Security Protocols: Supports multiple encryption and firewall settings for network protection.

  • External Antenna Support: Includes external antenna ports to boost LTE signal strength in weak reception areas.

Setup Guide

  1. Insert SIM Card: Insert the micro SIM card into the slot at the bottom of the router until it clicks into place.

  2. Connect Power: Plug in the supplied power adapter into the router and then into a power outlet.

  3. Power On: If the router does not turn on automatically, press the power button on the top. Indicator lights will show signal strength and network connectivity.

  4. Connect Devices:

    • Via Wi-Fi: Connect to the wireless network using the SSID and password printed on the label at the bottom of the router.

    • Via Ethernet: Use an Ethernet cable to connect your device to any of the LAN ports on the back.

  5. Access Router Interface: Open a browser and enter the default IP address (192.168.8.1 or 192.168.1.1) to log in using default credentials (found on the label) for further settings customization.

Price

The SoyeaLink B535-333 LTE Router typically retails around £85 to £90, making it an affordable option for high-speed LTE home and office connectivity.

Prices can vary based on region, retailer, and included accessories.

Manual and Support

The user manual for the SoyeaLink B535-333 LTE Router provides detailed instructions on setup, management, troubleshooting, and safety information. It covers:

  • Insertion/removal of SIM card

  • Router interface navigation and configuration

  • Wireless security settings

  • Firmware updates and maintenance

  • Safety precautions

The manual is often available via the official product website or manuals.plus and can be downloaded as a PDF for comprehensive guidance.

Key Use Cases

The SoyeaLink B535-333 LTE router is ideal for delivering fast broadband internet via LTE to homes or offices where fixed-line fiber or cable internet is unavailable or unreliable.

The combination of strong LTE capability, dual-band Wi-Fi, and multiple Ethernet ports makes it flexible for diverse networking needs.

External antenna support improves connectivity in weak-signal areas.

Physical and Power

  • Dimensions: Approx. 219 mm x 138 mm x 25.6 mm

  • Power: 12V/1A adapter, typical consumption max 12W

Conclusion

The SoyeaLink B535-333 LTE Router combines high-speed LTE internet access, flexible wired and wireless connectivity, easy setup, and strong security features—making it a reliable choice for users needing stable 4G broadband at home or work.

It is a robust, feature-rich LTE gateway delivering high-speed 4G internet with versatile connection options, external antenna support, and secure networking suited for home and small office environments worldwide.
