The ZTE MF971L is a portable LTE Cat 6 mobile Wi-Fi router designed to deliver fast internet connectivity and support multiple devices simultaneously, ideal for both personal and business use.

Overview

The ZTE MF971L is a compact, lightweight 4G LTE mobile hotspot router that supports LTE Cat 6 offering download speeds up to 300 Mbps and upload speeds up to 50 Mbps.

It provides reliable high-speed internet access on the go for up to 32 wireless devices.

Powered by a built-in rechargeable battery, it is highly portable, supporting dual-band Wi-Fi (2.4 GHz and 5 GHz) with modern wireless standards.

Specifications

  • Network: LTE Cat 6 with Carrier Aggregation

  • 4G Bands: FDD B1/2/3/4/5/7/8/20/28 and TDD B38/B40/B41

  • 3G Bands: DC-HSPA+/HSPA+/UMTS B1/B2/B4/B5/B8

  • 2G Bands: GSM/GPRS/EDGE

  • Wi-Fi: Dual band 802.11 b/g/n/ac (2.4 GHz and 5 GHz)

  • Max Speed: Download up to 300 Mbps / Upload up to 50 Mbps

  • Battery: Built-in 2300 mAh lithium-ion battery, up to 11 hours runtime, up to 500 hours standby

  • Devices Supported: Up to 32 Wi-Fi users simultaneously

  • Display: 1.44-inch TFT LCD

  • SIM Slot: Micro SIM

  • Ports: Micro USB for charging, 2x TS-9 external antenna connectors

  • Dimensions: Approx. 104 x 65 x 14 mm

  • Weight: Around 100 g

Key Features

  • LTE Cat 6 with Carrier Aggregation enhances bandwidth and speed

  • Dual-band Wi-Fi for improved connectivity and less interference

  • Supports up to 32 devices simultaneously for multi-user environments

  • Small LCD screen for network status, battery level, and SMS alerts

  • External antenna support for improved signal in low coverage areas

  • Compact, lightweight design ideal for travel and remote working

  • Long-lasting battery for all-day connectivity without a power source

Performance

The ZTE MF971L provides smooth, high-speed internet capable of handling standard household and small office needs.

Its dual-band Wi-Fi ensures stable connections, while carrier aggregation boosts data throughput.

Battery life supports extended use away from power outlets, making it practical for business trips or outdoor use.

It has a responsive web management interface for easy network configuration and monitoring.

Step-by-Step Setup

  1. Insert the Micro SIM card into the designated SIM slot.

  2. Power on the device by pressing and holding the power button until the screen lights up.

  3. Wait for the device to connect to the LTE network (indicators will show signal strength).

  4. Connect to the Wi-Fi network broadcasted by the MF971L using the default SSID and password found on the device label or display.

  5. Access the web management portal by visiting the router’s IP address (usually 192.168.0.1) in a browser.

  6. Log in (default username and password is often “admin”).

  7. Configure Wi-Fi settings, check device status, and manage connections through the portal.

Firmware Update

Firmware updates can be installed via the web management interface to improve functionality or security. To update:

  • Connect to the router and log into the web portal.

  • Navigate to the system settings or firmware section.

  • Check for available updates online or download the firmware file from the official ZTE website.

  • Upload the firmware through the interface and wait for the device to reboot.

  • Ensure power is not interrupted during updates to avoid damage.

Price

The ZTE MF971L typically retails between $80 to $120 USD, depending on region and vendor. Prices vary based on included accessories and local taxes.

Conclusion

The ZTE MF971L is a reliable, compact mobile Wi-Fi hotspot router with robust LTE Cat 6 speeds and support for multiple devices.

Its lightweight design, long battery life, and easy setup make it suitable for travel, remote work, or everyday internet sharing needs.

With external antenna options and dual-band Wi-Fi, it offers flexibility and strong connectivity.

Firmware updates and a user-friendly management interface ensure continued usability, positioning the ZTE MF971L as a solid choice for those looking for portable, high-speed wireless internet access.

This comprehensive overview should help users understand the capabilities, setup, and benefits of the ZTE MF971L mobile router.
